"Designed in Germany, Manufactured in India"
SECURE Boom Barrier (SBG-50) is the ideal solution for professional parking applications. The SBG-50 is designed for heavy and frequent use in Parking lots. Its rapid opening times and tailgating vehicles detection ensure reliable operation, while low power consumption, minimal-maintenance and easy of use make it highly efficient.
The SBG-50 is designed and tested for 5 million opening and closing cycles.
| Barrier width | Up to 6 meters |
| Opening/closing time | 5 – 6 seconds |
| Power consumption | Max. 120 W |
| Drive technology | BLDC Drive Mechanism |
| Voltage | 230 VAC, 50/60 Hz |
| Duty cycle | 100% (Continuous Operation) |
| Housing dimensions (W x D x H) | 335 x 300 x 1050 mm |
| Enclosure rating | IP 54 (Tested by Indian Government Approved NABL Accredited LAB) |
| Temperature range | -30 to +60 °C |
| Weight | 60 kg |
| Interface | NO NC , RS485 (Optional) |
SECURE Boom Barrier (SBG-100) is the ideal solution for residential and commercial parking applications. The SBG-100 is designed for heavy-duty use. Rapid opening times and tailgating vehicles detection ensure reliable operation for users, while low power consumption, minimal-maintenance and easy of use make it highly efficient.
The SBG-100 Barriers available with boom breakaway option , in the event of a forced, unauthorized passage, the boom is completely released and can be reattached without affecting functionality
The SBG-100 is designed and tested for 10 million opening and closing cycles.
| Barrier width | Max. 5 m |
| Opening/closing time | 1.5 s/ 3 s / 4.5 s |
| Power consumption | Max. 100 W |
| Drive technology | BLDC Drive Mechanism |
| Voltage | 230 VAC, 50/60 Hz |
| Duty cycle | 100% |
| Housing dimensions (W x D x H) | 330 x 245 x 981 mm |
| Enclosure rating | IP 54 (Tested by Indian Government Approved NABL Accredited LAB) |
| Temperature range | -30 to +60 °C |
| Weight | 40 kg |
| Interface | NO NC , RS485 (Optional) |
SECURE Boom Barrier (SBG-200) is the ideal solution for residential and commercial parking applications. The SBG-200 is designed for heavy-duty use. Rapid opening times and tailgating vehicles detection ensure reliable operation for users, while low power consumption, minimal maintenance and ease of use make it highly efficient.
The SBG-200 barrier comes with an Anti-pet feature or LED Boom , The SBG-200 is designed and tested for 10 million opening and closing cycles.
| Barrier width | Max. 5 m |
| Opening/closing time | 1.5 s/ 3 s / 4.5 s |
| Power consumption | Max. 100 W |
| Drive technology | BLDC Drive Mechanism |
| Voltage | 230 VAC, 50/60 Hz |
| Duty cycle | 100% |
| Housing dimensions (W x D x H) | 320 x 270 x 1018 mm |
| Enclosure rating | IP 54 (Tested by Indian Government Approved NABL Accredited LAB) |
| Temperature range | -30 to +60 °C |
| Weight | 40 kg |
| Interface | NO NC , RS485 (Optional) |
SECURE TOLL Barrier (SBG-400) is the ideal solution for toll plazas. The SBG-400 is designed for high-intensive use. Rapid opening times and tailgating vehicles detection ensure reliable operation for users, while low power consumption, minimal maintenance, and ease of use make it highly efficient.
The SBG-400 toll barrier is available with a boom breakaway option -in the event of a forced unauthorized passage, the boom is completely released and can be reattached without any impairment of function. The SBG-400 is designed and tested for 10 million opening and closing cycles.
| Barrier width | Max. 3 m |
| Opening/closing time | 0.6 s / 0.9 s |
| Power consumption | Max. 100 W |
| Drive technology | DC Brushless Servo Torque Motor Drive Mechanism |
| Voltage | 230 VAC, 50/60 Hz |
| Duty cycle | 100% |
| Housing dimensions (W x D x H) | 329 x 320 x 950 mm |
| Enclosure rating | IP 54 (Tested by Indian Government Approved NABL Accredited LAB) |
| Temperature range | -30 to +60 °C |
| Weight | 40 kg |
| Interface | NO NC , RS485 / TCP IP/RJ45 (Optional) |
Automation for barriers with bars up to 4 and 6 m long
RELEASE SYSTEM: Strong and reliable key release rystem
BAR: Elliptic profile in painted aluminium
CONTROL UNIT: Wide lodging for control unit and electric wirings
